Analysis of Storm-0558 techniques for unauthorized email access

Executive summary

On July 11, 2023, Microsoft published two blogs detailing a malicious campaign by a threat actor tracked as Storm-0558 that targeted customer email that we’ve detected and mitigated: Microsoft Security Response Center and Microsoft on the Issues. As we continue our investigation into this incident and deploy defense in depth measures to harden all systems involved, we’re providing this deeper analysis of the observed actor techniques for obtaining unauthorized access to email data, tools, and unique infrastructure characteristics.

September 6, 2023 update – Microsoft has completed a comprehensive technical investigation into Storm-0558’s acquisition of the Microsoft account consumer signing key. Investigation findings are released on the Microsoft Security Response Center blog: Results of major technical investigations for Storm-0558 key acquisition

As described in more detail in our July 11 blogs, Storm-0558 is a China-based threat actor with espionage objectives. Beginning May 15, 2023, Storm-0558 used forged authentication tokens to access user email from approximately 25 organizations, including government agencies and related consumer accounts in the public cloud. No other environment was impacted. Microsoft has successfully blocked this campaign from Storm-0558. As with any observed nation-state actor activity, Microsoft has directly notified targeted or compromised customers, providing them with important information needed to secure their environments.

Since identification of this malicious campaign on June 16, 2023, Microsoft has identified the root cause, established durable tracking of the campaign, disrupted malicious activities, hardened the environment, notified every impacted customer, and coordinated with multiple government entities. We continue to investigate and monitor the situation and will take additional steps to protect customers.

Actor overview

Microsoft Threat Intelligence assesses with moderate confidence that Storm-0558 is a China-based threat actor with activities and methods consistent with espionage objectives. While we have discovered some minimal overlaps with other Chinese groups such as Violet Typhoon (ZIRCONIUM, APT31), we maintain high confidence that Storm-0558 operates as its own distinct group.

Figure 1 shows Storm-0558 working patterns from April to July 2023; the actor’s core working hours are consistent with working hours in China, Monday through Friday from 12:00 AM UTC (8:00 AM China Standard time) through 09:00 AM UTC (5:00 PM China Standard Time).

Heatmap showing observed Storm-0558 activity by day of the week (x-axis) and hour (y-axis).
Figure 1. Heatmap of observed Stom-0558 activity by day of week and hour (UTC).

In past activity observed by Microsoft, Storm-0558 has primarily targeted US and European diplomatic, economic, and legislative governing bodies, and individuals connected to Taiwan and Uyghur geopolitical interests.

Historically, this threat actor has displayed an interest in targeting media companies, think tanks, and telecommunications equipment and service providers. The objective of most Storm-0558 campaigns is to obtain unauthorized access to email accounts belonging to employees of targeted organizations. Storm-0558 pursues this objective through credential harvesting, phishing campaigns, and OAuth token attacks. This threat actor has displayed an interest in OAuth applications, token theft, and token replay against Microsoft accounts since at least August 2021. Storm-0558 operates with a high degree of technical tradecraft and operational security. The actors are keenly aware of the target’s environment, logging policies, authentication requirements, policies, and procedures. Storm-0558’s tooling and reconnaissance activity suggests the actor is technically adept, well resourced, and has an in-depth understanding of many authentication techniques and applications.

In the past, Microsoft has observed Storm-0558 obtain credentials for initial access through phishing campaigns. The actor has also exploited vulnerabilities in public-facing applications to gain initial access to victim networks. These exploits typically result in web shells, including China Chopper, being deployed on compromised servers. One of the most prevalent malware families used by Storm-0558 is a shared tool tracked by Microsoft as Cigril. This family exists in several variants and is launched using dynamic-link library (DLL) search order hijacking.

After gaining access to a compromised system, Storm-0558 accesses credentials from a variety of sources, including the LSASS process memory and Security Account Manager (SAM) registry hive. Microsoft assesses that once Storm-0558 has access to the desired user credentials, the actor signs into the compromised user’s cloud email account with the valid account credentials. The actor then collects information from the email account over the web service.

Initial discovery and analysis of current activity

On June 16, 2023, Microsoft was notified by a customer of anomalous Exchange Online data access. Microsoft analysis attributed the activity to Storm-0558 based on established prior TTPs. We determined that Storm-0558 was accessing the customer’s Exchange Online data using Outlook Web Access (OWA). Microsoft’s investigative workflow initially assumed the actor was stealing correctly issued Azure Active Directory (Azure AD) tokens, most probably using malware on infected customer devices. Microsoft analysts later determined that the actor’s access was utilizing Exchange Online authentication artifacts, which are typically derived from Azure AD authentication tokens (Azure AD tokens). Further in-depth analysis over the next several days led Microsoft analysts to assess that the internal Exchange Online authentication artifacts did not correspond to Azure AD tokens in Microsoft logs.

Microsoft analysts began investigating the possibility that the actor was forging authentication tokens using an acquired Azure AD enterprise signing key. In-depth analysis of the Exchange Online activity discovered that in fact the actor was forging Azure AD tokens using an acquired Microsoft account (MSA) consumer signing key. This was made possible by a validation error in Microsoft code. The use of an incorrect key to sign the requests allowed our investigation teams to see all actor access requests which followed this pattern across both our enterprise and consumer systems. Use of the incorrect key to sign this scope of assertions was an obvious indicator of the actor activity as no Microsoft system signs tokens in this way. Use of acquired signing material to forge authentication tokens to access customer Exchange Online data differs from previously observed Storm-0558 activity. Microsoft’s investigations have not detected any other use of this pattern by other actors and Microsoft has taken steps to block related abuse.

Actor techniques

Token forgery

Authentication tokens are used to validate the identity of entities requesting access to resources – in this case, email. These tokens are issued to the requesting entity (such as a user’s browser) by identity providers like Azure AD. To prove authenticity, the identity provider signs the token using a private signing key. The relying party validates the token presented by the requesting entity by using a public validation key. Any request whose signature is correctly validated by the published public validation key will be trusted by the relying party. An actor that can acquire a private signing key can then create falsified tokens with valid signatures that will be accepted by relying parties. This is called token forgery.

Storm-0558 acquired an inactive MSA consumer signing key and used it to forge authentication tokens for Azure AD enterprise and MSA consumer to access OWA and All MSA keys active prior to the incident – including the actor-acquired MSA signing key – have been invalidated. Azure AD keys were not impacted. The method by which the actor acquired the key is a matter of ongoing investigation. Though the key was intended only for MSA accounts, a validation issue allowed this key to be trusted for signing Azure AD tokens. This issue has been corrected.

As part of defense in depth, we continuously update our systems. We have substantially hardened key issuance systems since the acquired MSA key was initially issued. This includes increased isolation of the systems, refined monitoring of system activity, and moving to the hardened key store used for our enterprise systems. We have revoked all previously active keys and issued new keys using these updated systems. Our active investigation indicates these hardening and isolation improvements disrupt the mechanisms we believe the actor could have used to acquire MSA signing keys. No key-related actor activity has been observed since Microsoft invalidated the actor-acquired MSA signing key. Further, we have seen Storm-0558 transition to other techniques, which indicates that the actor is not able to utilize or access any signing keys. We continue to explore other ways the key may have been acquired and add additional defense in depth measures.

Identity techniques for access

Once authenticated through a legitimate client flow leveraging the forged token, the threat actor accessed the OWA API to retrieve a token for Exchange Online from the GetAccessTokenForResource API used by OWA. The actor was able to obtain new access tokens by presenting one previously issued from this API due to a design flaw. This flaw in the GetAccessTokenForResourceAPI has since been fixed to only accept tokens issued from Azure AD or MSA respectively. The actor used these tokens to retrieve mail messages from the OWA API.

Actor tooling

Microsoft Threat Intelligence routinely identifies threat actor capabilities and leverages file intelligence to facilitate our protection of Microsoft customers. During this investigation, we identified several distinct Storm-0558 capabilities that facilitate the threat actor’s intrusion techniques. The capabilities described in this section are not expected to be present in the victim environment.

Storm-0558 uses a collection of PowerShell and Python scripts to perform REST API calls against the OWA Exchange Store service. For example, Storm-0558 has the capability to use minted access tokens to extract email data such as:

The generated web requests can be routed through a Tor proxy or several hardcoded SOCKS5 proxy servers. The threat actor was observed using several User-Agents when issuing web requests, for example:

The scripts contain highly sensitive hardcoded information such as bearer access tokens and email data, which the threat actor uses to perform the OWA API calls. The threat actor has the capability to refresh the access token for use in subsequent OWA commands.

Screenshot of Python code snippet of the token refresh functionality
Figure 2. Python code snippet of the token refresh functionality used by the threat actor.
Screenshot of PowerShell code snippet of OWA REST API
Figure 3. PowerShell code snippet of OWA REST API call to GetConversationItems.

Actor infrastructure

During significant portions of Storm-0558’s malicious activities, the threat actor leveraged dedicated infrastructure running the SoftEther proxy software. Proxy infrastructure complicates detection and attribution of Storm-0558 activities. During our response, Microsoft Threat Intelligence identified a unique method of profiling this proxy infrastructure and correlated with behavioral characteristics of the actor intrusion techniques. Our profile was based on the following facets:

  1. Hosts operating as part of this network present a JARM fingerprint consistent with SoftEther VPN: 06d06d07d06d06d06c42d42d000000cdb95e27fd8f9fee4a2bec829b889b8b.
  2. Presented x509 certificate has expiration date of December 31, 2037.
  3. Subject information within the x509 certificate does not contain “softether”.

Over the course of the campaign, the IPs listed in the table below were used during the corresponding timeframes.

IP addressFirst seenLast seenDescription
51.89.156[.]1533/9/20237/10/2023SoftEther proxy
176.31.90[.]1293/28/20236/29/2023SoftEther proxy
137.74.181[.]1003/31/20237/11/2023SoftEther proxy
193.36.119[.]454/19/20237/7/2023SoftEther proxy
185.158.248[.]1594/24/20237/6/2023SoftEther proxy
131.153.78[.]1885/6/20236/29/2023SoftEther proxy
37.143.130[.]1465/12/20235/19/2023SoftEther proxy
146.70.157[.]455/12/20236/8/2023SoftEther proxy
185.195.200[.]395/15/20236/29/2023SoftEther proxy
185.38.142[.]2295/15/20237/12/2023SoftEther proxy
146.70.121[.]445/17/20236/29/2023SoftEther proxy
31.42.177[.]1815/22/20235/23/2023SoftEther proxy
185.51.134[.]526/7/20237/11/2023SoftEther proxy
173.44.226[.]706/9/20237/11/2023SoftEther proxy
45.14.227[.]2336/12/20236/26/2023SoftEther proxy
185.236.231[.]1096/12/20237/3/2023SoftEther proxy
178.73.220[.]1496/16/20237/12/2023SoftEther proxy
45.14.227[.]2126/19/20236/29/2023SoftEther proxy
91.222.173[.]2256/20/20237/1/2023SoftEther proxy
146.70.35[.]1686/22/20236/29/2023SoftEther proxy
146.70.157[.]2136/26/20236/30/2023SoftEther proxy
31.42.177[.]2016/27/20236/29/2023SoftEther proxy
5.252.176[.]87/1/20237/1/2023SoftEther proxy
80.85.158[.]2157/1/20237/9/2023SoftEther proxy
193.149.129[.]887/2/20237/12/2023SoftEther proxy
5.252.178[.]687/3/20237/11/2023SoftEther proxy
116.202.251[.]87/4/20237/7/2023SoftEther proxy
185.158.248[.]936/25/202306/26/2023SoftEther proxy
20.108.240[.]2526/25/20237/5/2023SoftEther proxy
146.70.135[.]1825/18/20236/22/2023SoftEther proxy

As early as May 15, 2023, Storm-0558 shifted to using a separate series of dedicated infrastructure servers specifically for token replay and interaction with Microsoft services. It is likely that the dedicated infrastructure and supporting services configured on this infrastructure offered a more efficient manner of facilitating the actor’s activities. The dedicated infrastructure would host an actor-developed web panel that presented an authentication page at URI /#/login. The observed sign-in pages had one of two SHA-1 hashes: 80d315c21fc13365bba5b4d56357136e84ecb2d4 and 931e27b6f1a99edb96860f840eb7ef201f6c68ec.

Screenshot of the token web panel sign-in page
Figure 4. Token web panel sign-in page with SHA-1 hashes.

As part of the intelligence-driven response to this campaign, and in support of tracking, analyzing, and disrupting actor activity, analytics were developed to proactively track the dedicated infrastructure. Through this tracking, we identified the following dedicated infrastructure.

IP addressFirst seenLast seenDescription
195.26.87[.]2195/15/20236/25/2023Token web panel
185.236.228[.]1835/24/20236/11/2023Token web panel
85.239.63[.]1606/7/20236/11/2023Token web panel
193.105.134[.]586/24/20236/25/2023Token web panel
146.0.74[.]166/28/20237/4/2023Token web panel
91.231.186[.]2266/29/20237/4/2023Token web panel
91.222.174[.]416/29/20237/3/2023Token web panel
185.38.142[.]2496/29/20237/2/2023Token web panel

The last observed dedicated token replay infrastructure associated with this activity was stood down on July 4, 2023, roughly one day following the coordinated mitigation conducted by Microsoft.

Post-compromise activity

Our telemetry and investigations indicate that post-compromise activity was limited to email access and exfiltration for targeted users.

Mitigation and hardening

No customer action is required to mitigate the token forgery technique or validation error in OWA or Microsoft has mitigated this issue on customers’ behalf as follows:

Ongoing monitoring indicates that all actor activity related to this incident has been blocked. Microsoft will continue to monitor Storm-0558 activity and implement protections for our customers.


Microsoft has mitigated this activity on our customers’ behalf for Microsoft services. No customer action is required to prevent threat actors from using the techniques described above to access Exchange Online and

Indicators of compromise

IndicatorTypeFirst seenLast seenDescription
d4b4cccda9228624656bff33d8110955779632aaThumbprint  Thumbprint of acquired signing key
195.26.87[.]219IPv45/15/20236/25/2023Token web panel
185.236.228[.]183IPv45/24/20236/11/2023Token web panel
85.239.63[.]160IPv46/7/20236/11/2023Token web panel
193.105.134[.]58IPv46/24/20236/25/2023Token web panel
146.0.74[.]16IPv46/28/20237/4/2023Token web panel
91.231.186[.]226IPv46/29/20237/4/2023Token web panel
91.222.174[.]41IPv46/29/20237/3/2023Token web panel
185.38.142[.]249IPv46/29/20237/2/2023Token web panel
51.89.156[.]153IPv43/9/20237/10/2023SoftEther proxy
176.31.90[.]129IPv43/28/20236/29/2023SoftEther proxy
137.74.181[.]100IPv43/31/20237/11/2023SoftEther proxy
193.36.119[.]45IPv44/19/20237/7/2023SoftEther proxy
185.158.248[.]159IPv44/24/20237/6/2023SoftEther proxy
131.153.78[.]188IPv45/6/20236/29/2023SoftEther proxy
37.143.130[.]146IPv45/12/20235/19/2023SoftEther proxy
146.70.157[.]45IPv45/12/20236/8/2023SoftEther proxy
185.195.200[.]39IPv45/15/20236/29/2023SoftEther proxy
185.38.142[.]229IPv45/15/20237/12/2023SoftEther proxy
146.70.121[.]44IPv45/17/20236/29/2023SoftEther proxy
31.42.177[.]181IPv45/22/20235/23/2023SoftEther proxy
185.51.134[.]52IPv46/7/20237/11/2023SoftEther proxy
173.44.226[.]70IPv46/9/20237/11/2023SoftEther proxy
45.14.227[.]233IPv46/12/20236/26/2023SoftEther proxy
185.236.231[.]109IPv46/12/20237/3/2023SoftEther proxy
178.73.220[.]149IPv46/16/20237/12/2023SoftEther proxy
45.14.227[.]212IPv46/19/20236/29/2023SoftEther proxy
91.222.173[.]225IPv46/20/20237/1/2023SoftEther proxy
146.70.35[.]168IPv46/22/20236/29/2023SoftEther proxy
146.70.157[.]213IPv46/26/20236/30/2023SoftEther proxy
31.42.177[.]201IPv46/27/20236/29/2023SoftEther proxy
5.252.176[.]8IPv47/1/20237/1/2023SoftEther proxy
80.85.158[.]215IPv47/1/20237/9/2023SoftEther proxy
193.149.129[.]88IPv47/2/20237/12/2023SoftEther proxy
5.252.178[.]68IPv47/3/20237/11/2023SoftEther proxy
116.202.251[.]8IPv47/4/20237/7/2023SoftEther proxy
