Microsoft has discovered a set of memory corruption vulnerabilities in a library called ncurses, which provides APIs that support text-based user interfaces (TUI). Released in 1993, the ncurses library is commonly used by various programs on Portable Operating System Interface (POSIX) operating systems, including Linux, macOS, and FreeBSD. Using environment variable poisoning, attackers could chain these vulnerabilities to elevate privileges and run code in the targeted program’s context or perform other malicious actions.

One of the most common vulnerabilities found in modern software, memory corruption vulnerabilities, can allow attackers to gain unauthorized access to systems and data by modifying a program’s memory. The impact of memory corruption vulnerabilities can range from leaking sensitive information and performing a simple denial-of-service (DoS) to elevating privileges and executing arbitrary code.

Microsoft has shared these vulnerabilities with the relevant maintainers through Coordinated Vulnerability Disclosure (CVD) via Microsoft Security Vulnerability Research (MSVR). Fixes for these vulnerabilities, now identified as CVE-2023-29491 with a CVSS score of 7.8, have been successfully deployed by the maintainers of the ncurses library, Thomas E. Dickey, in commit 20230408. We wish to thank Thomas for his professionalism and collaboration in resolving those issues. We also worked with Apple on addressing the macOS-specific issues related to these vulnerabilities, and we thank Apple for their response and partnership. Lastly, during our analysis, a researcher named Gergely Kalman engaged us privately over Twitter and contributed relevant use cases in addition to his own hand-coded fuzzer. We thank Gergely for his contributions in advancing this research and community engagement. Users of ncurses are encouraged to update their instances and systems.

In this blog post, we share information about ncurses and the discovered memory corruption vulnerabilities. We also share this research to emphasize the importance of collaboration among researchers, industry partners, and the larger security community in the effort to improve security for all.

Understanding terminal databases

Terminal databases are used by ncurses to be terminal-independent, meaning the capabilities of the terminal are not required to be known ahead-of-time. Terminal databases contain a set of capabilities that ultimately determine the control characters that are sent to the terminal (instructing the terminal to perform basic interactions) and describe various properties of the terminal. Terminal databases come in two major formats: the older and less commonly used termcap (terminal capability) format, and the improved terminfo format. Since terminals can differ on the types of control characters they expect and the operations they support, terminfo became necessary to address this discrepancy.  In its textual syntax, capabilities are separated by commas, and come in three forms:

POSIX systems usually pre-ship with tens of such databases. It’s possible to parse the capabilities of the current database with the infocmp utility:

Screenshot of the infocmp utility code output
Figure 1. infocmp output reveals the current terminfo database along with its capabilities

Environment variable poisoning

Every modern operating system contains a set of environment variables that might affect the behavior of programs. A well-known technique for attackers is to manipulate those environment variables to cause programs to perform actions that would benefit their malicious purposes, hence “poisoning” them. There have been multiple cases of environment variable poisoning in the past, for instance:

We have discovered that during initialization, the ncurses library searches for several environment variables, including an environment variable similarly named TERMINFO. When using terminfo databases, the program consults a fixed directory path unless a TERMINFO environment variable is present, which instead points the program to an alternative directory that contains compiled terminfo database files. Moreover, there are interesting common programs that use ncurses, most notably top on macOS, which is a set-UID binary (which runs with elevated privileges) that also uses the TERMINFO environment variable. Therefore, finding vulnerabilities in ncurses have the potential to affect many programs and possibly elevate privileges. It’s noteworthy that the potential of poisoning the TERMINFO environment variable was highlighted several times in the past (for example, here), but we have not seen comprehensive research on the topic of terminfo capabilities for offensive security purposes.

For completeness, while this blog post focuses on how attackers could poison the TERMINFO environment variable to potentially exploit ncurses vulnerabilities, the HOME environment variable could have been similarly manipulated. Assuming the TERMINFO environment variable was never defined, ncurses looks for a $HOME/.terminfo directory. This could have been abused by planting a .terminfo directory at an arbitrary path and poisoning the HOME environment variable, so the technique is quite similar.

Stack-based terminfo capabilities

The terminfo capabilities are richer than they first appear. In a nutshell, capabilities are allowed to receive up to nine parameters (p1-p9) and use them in a stack data structure. Furthermore, capabilities work with a stack-like structure and instructions that can push (place an item in the stack) and pop (get an item from the stack) data, perform logical-arithmetic operations, and even support conditions. Here are some examples:

%{number}Push a constant value to the stack.
%pxPush the parameter to the stack.
%+, %-, %*, %/, %mPop two numbers from the stack and push the arithmetic result of the stack. Addition, substruction, multiplication, division, and remainder operations are supported.
%&, %|, %^Pop two numbers from the stack and push the bitwise result to the stack. Bitwise OR, AND, and XOR are supported.
%=, %<, %>, %A, %OPop two numbers and compare them, pushing the logical result back to the stack. The operations of comparison, less-than, and greater-than are supported, as well as logical AND and OR operations.
%lPop a string from the stack and push its length back to the stack.
%?[condition]%t[body1]%e[body2]%;Perform a condition. The %t operation pops a numeric value from the stack and compares it to 0. The result determines what body to execute (the “else” body is optional and comes after the %e delimiter).
%s, %cPop a string from the stack and print it out to the terminal.
%d, %xPop a number from the stack and print it out to the terminal.

While not Turing-complete, terminfo offers functionality that resembles very basic programming. Due to the complicated logic required by ncurses, security issues are expected to be found, and indeed there have been numerous ncurses vulnerabilities in the past.

It’s interesting to note that while the version of ncurses we checked was 6.4 (latest at the time of research), the ncurses version on macOS was 5.7, but had several security-related patches maintained by Apple. Nevertheless, all our findings are true for all ncurses versions, thus affecting both Linux and macOS.

Discovered vulnerabilities

We discovered several memory corruption vulnerabilities through code auditing and fuzzing. In addition to using our own AFL++ based fuzzer, the use cases contributed by Gergely Kalman assisted in advancing this research.

The discovered vulnerabilities could have been exploited by attackers to elevate privileges and run code within a targeted program’s context. Nonetheless, gaining control of a program through exploiting memory corruption vulnerabilities requires a multi-stage attack. The vulnerabilities may have needed to be chained together for an attacker to elevate privileges, such as exploiting the stack information leak to gain arbitrary read primitives along with exploiting the heap overflow to obtain a write primitive.

Stack information leak

The function that runs the capability logic is called tparm. It is a C variadic function, meaning its number of arguments is not predefined (similarly to printf). The way variadic functions work in C is usually with the va_list structure and its macros, va_start, va_arg, and va_end. The common scenario for such functions is to parse a format-string, conclude the number of parameters it expects, and use the va_arg macro iteratively to fetch those arguments. However, since an attacker can be in full control of the capability’s string, we can make tparm call va_arg more times than it should, effectively leaking information from the call stack. Since we are allowed up to nine parameters, we can leak up to eight unintended arguments, including arguments from the program’s stack:

Screenshot of code
Figure 2. Demonstrating an information leak proof of concept

Parameterized string type confusion

The stack used by the tparm function is just an allocated array with 20 entries (referred as STACK_FRAME in the source code). Each frame can hold either a number (32-bit signed integer) or a string (pointer). To distinguish between a number and a string, the frame uses a Boolean value, which represents whether the data is numeric or not:

Screenshot of code
Figure 3. A terminfo stack entry

Certain push operations can be easily concluded, for example, when pushing an arithmetic result (such as %+) or a literal (%{number}). However, for parameters, things are different. There is no easy way to know ahead of time whether a parameter is expected to be a string or numeric. Therefore, tparm uses a heuristic—it walks the capability string statically, and when it sees %s or %l, it concludes that the last parameter push was a string. This approach can be abused in multiple ways. For example, the macOS top utility calls mvcur, which in turn calls tparm with the cup capability, along with integer parameters. Treating the parameter as a string can trigger strlen on the integer address:

Screenshot of code
Figure 4. Type confusion causes strlen to be invoked on low addresses

The crash we triggered occurs during an initialization of the mvcur operation, which assesses the “cost” of moving the cursor by invoking tparm with a constant, non-attacker-controlled value. We can improve the attack by using conditions—if the parameter’s value is not that constant value, then treat the parameter as a string, otherwise treat it as a number. Implementation with capabilities is straightforward:

A line of code reading cup=%?%p1%p2%<%t\E[%i%p1%d;%p2%dH%e%p1%s%;,

This should be read as:

Screenshot stating “IF p1 < p2 THEN (use the usual ‘cup’ capability) ELSE treat p1 is a string”
Screenshot of code
Figure 5. Using conditions to only trigger strlen when desired

This primitive is quite powerful, as we can trigger strlen on an arbitrary number, effectively gaining a read primitive. Gaining a read primitive defeats the Address Space Layout Randomization (ASLR) security mechanism to leak address information and, if the binary happens to contain valuable secrets in its memory (like passwords), an attacker could potentially read those as well.

Cost calculating padding off-by-one

We have mentioned mvcur uses a cost-calculating function to determine the costs of certain capabilities. The cost-calculation is done by the function _nc_msec_cost, and it assesses the number of milliseconds it takes to print out a capability, which is strongly derived by delays that could be a part of a capability. Delays are numeric literal values wrapped between ‘$<’ and ‘>’, and they even support a decimal point. We discovered an off-by-one error—if the function sees a decimal point character, it skips one character assuming a digit, with an insufficient check after:

Screenshot of code
Figure 6. Off-by-one bug causes the string to be assessed beyond its boundaries

Therefore, it’s possible to have the cost-calculating function read beyond the boundary of the capability string by closing the delay markup with a ‘>’ character immediately following the decimal dot.

Screenshot of code
Figure 7. Reading past the capability string limit might cause a segmentation fault

Heap out-of-bounds during terminfo database file parsing

The terminfo database files are binary files commonly compiled from the text representation with a utility called tic. The format of the database consists of the following parts:

The optional extended entries are user-defined entries. We discovered that the function that performs that database parsing (_nc_read_termtype) can write beyond the boundaries of a heap-allocated chunk, as such:

Screenshot of code
Figure 8. Heap out-of-bounds due to realloc call
  1. The code uses calloc to allocate room for the strings. While STRCOUNT is a constant representing the maximum length of standard string capabilities (414), str_count is attacker-controlled and defined in the header of the attacker’s terminfo file. This controls the size of the allocated chunk saved in ptr->Strings.
  2. After parsing all the standard capabilities, ncurses starts parsing the extended capabilities. The code assigns ptr->num_Strings to STRCOUNT+ ext_str_count, which might be smaller than the non-extended string count, effectively shrinking ptr->Strings with a realloc call.
  3. Immediately after the realloc call, we can see ptr->Strings being written beyond its boundaries. Extended string capabilities are parsed and appended after standard string capabilities. The convert_strings function attempts to achieve this by storing data in ptr->Strings + str_count. However, while ptr->Strings was shrunk to STRCOUNT+ext_str_countstr_count is user-controlled and can be greater than STRCOUNT.
  4. If str_count >= STRCOUNT, then ptr->Strings + str_count + ext_str_count will be greater than ptr->Strings + STRCOUNT + ext_str_count and convert_strings will cause a heap buffer overflow.

Denial of service with canceled strings

The ncurses library has a notion of marking strings as “cancelled”. This is useful for terminfo database inheritance and skipping absent capabilities in general. As an example, the function convert_strings that converts strings from the terminfo database file format to the appropriate data structures in memory sets strings as CANCELLED_STRING if the index referring to them is negative.

Screenshot of code
Figure 9. convert_strings setting a string to be CANCELLED

The value of the CANCELLED_STRING constant is -1, and before processing, the ncurses codebase looks for these strings and converts them to ABSENT_STRING (constant 0). Unfortunately, it does so only for ordinary strings; extended strings do not get that treatment. Specifically, a heuristic determines that strings that begin with the “k” character should be treated as keypad functionality. This allows an attacker to specify an extended string in a way that will make ncurses dereference -1 (0xFFFFFFFFFFFFFFFF):

Screenshot of code
Figure 10. ncurses dereferencing -1 when attempting to parse a cancelled string for keypad functionality

Protection and detection with Microsoft Defender for Endpoint

While organizational devices and networks may become increasingly secure, attackers continue to exploit unpatched vulnerabilities and misconfigurations as a vector to access sensitive systems and information. Exploiting vulnerabilities in the ncurses library could have notable consequences for users, allowing attackers to perform malicious actions like elevating privileges to run code in a targeted program’s context and access or modify valuable data and resources. Responding to the evolving threat landscape requires us to expand our expertise across devices and platforms as part of our commitment to continuously improve security from Microsoft, not just for Microsoft.

This case displays how responsible vulnerability disclosure and collaborative research informs our comprehensive protection capabilities across platforms. Microsoft Defender Vulnerability Management is able to quickly discover and remediate such vulnerabilities on both Linux and macOS. Additionally, Microsoft Defender for Endpoint has similar detections for potential abuse of terminfo databases for set-UID binaries, such as macOS’s top:

Screenshot of code
Figure 11. Microsoft Defender for Endpoint detecting suspicious TERMINFO use

After discovering the vulnerabilities in the ncurses library, we worked with the maintainer, Thomas E. Dickey, and Apple to ensure the issues were resolved across platforms. Additionally, this case displays the value of community engagement to improve security for all as researcher Gergely Kalman’s use case contributions assisted our research efforts. We wish to again thank Thomas and the Apple product security team for their efforts and collaboration in addressing CVE-2023-29491, as well as Gergely for his contributions in furthering this research.

As the threat landscape continues to evolve and threats across all platforms continue to grow, Microsoft strives to continuously secure users’ computing experiences, regardless of the platform or device in use. We will continue to work with the security community to share vulnerability discoveries and threat intelligence in the effort to build better protection for all.

Jonathan Bar Or, Emanuele Cozzi, Michael Pearse

Microsoft Threat Intelligence team
